MULTRON MT-04 Pro
MT-04 Pro Ackermann Steering Mobile Robot
High-speed robot of increased load capacity for transportation of large loads at high speed.
Applications
Warehouse logistics, construction, R&D, autonomous driving
Features
- Overcoming obstacles up to 8 cm
- lift-off
Technical specifications
Series
MT
Full Name
MT-04 Pro Ackermann Steering Mobile Robot
Type/Category
Ackerman steering robot (front wheels)
Appointment
High-speed robot of increased load capacity for transportation of large loads at high speed.
Dimensions (WxW), mm
1535×810×465
Weight, kg
110
Maximum speed, m/s
2.4
Load capacity, kg
200
Working hours, h
2-3
ACB voltage, B
48
Capacity of ACB, Ah
20
Type of movement
Front wheel drive, rear wheel drive, Ackerman
Navigation
3D SLAM laser navigation, RTK navigation
Precision of positioning
10 см (RTK)
Communication Protocols
CAN, ROS/Ubuntu
Features
Overcoming obstacles up to 8 cm, lifting 20 ° without load
Sensors
16-line 3D LiDAR, RTK module, depth camera, IMU, bumper, industrial computer
Application
Warehouse logistics, construction, R&D, autonomous driving
